ABB solutions to power up Mauritanian gold mine

ABB Electrification will provide an end-to-end switchgear and circuit breaker solution to the Tasiast 24k mining plant in Mauritania, in line with the plant's objectives to significantly reduce emissions through the use of renewable energy.

Tasiast 24k in Mauritania is operated by Canadian gold mining company Kinross and has recently increased capacity to 24,000 tonnes of gold per day while reducing costs.

ABB specified 15 SF6-free and robust UniGear ZS2 air insulated switchgear panels will be used. These offer additional benefits such as a smaller footprint, easy maintenance and assembly, plus withdrawable voltage transformer.

Have you read?
ABB tech selected for Norway’s HyPilot green hydrogen project
ABB retrofit to boost uptime of Swedish cogeneration plant

The solution also included 13 of ABB’s market leading VD4 vacuum circuit breakers – there are more than 2 million in active operation globally – which minimize maintenance and costly downtime, increase safety and provide primary and secondary protection guarantees.

Additionally, ABB is partnering with Voltalia to help with the systems integration and value chain of the new project.

Despite already being covered for protection relays, IED and energy meters, the main MV switchgear required integration in the Low Voltage Compartment (LVC) and interoperability with other devices from different manufacturers, so that all components operated in conjunction, complementing each others functions and meeting all customer demands.

To help meet their sustainability targets an integrated PV solar plant has been finalised with power generation capacity of 34MW and a battery system of 18MW, to provide around 20% of the site’s power.

The Tasiast solar project is expected to reduce GHG emissions by approximately 530kt over the life of the mine, which could save approximately 180 million litres of fuel over the same period. The new scheme is also contributing to the Government of Mauritania’s GHG reduction targets in the country.

Jeremy Martin, project manager at Voltalia SA, said: “Working with ABB on the Tasiast solar project was again a good experience. ABB's technical expertise played a key role in achieving our objectives for this project. Working alongside a committed partner like ABB reinforces our belief that collaboration can bring about real change.”

ABB technology manages compact dimensions free of SF6 insulating gas in the switchgear or the circuit breaker – without compromising performance, safety or reliability – which was a key differentiator for both Voltalia and Kinross.

According to ABB, with the relays taking up significant space and having to be fitted within the confines of the LVC door, without interfering with the wiring and other components, the ZS2’s footprint flexibility proved ideal.

For extra features protection, ABB also integrated two relays in one panel and the Relion RED615, with its superior line differential protection and control for incomer units, complemented the functionality required and fitted in the tight LVC door front access.

Nuno Nunes, sales engineer at ABB Portugal, added: “The mining industry is committed to reducing its emissions and integrating more renewable energy sources, so it was great to be involved in this innovative project, which uses our space-saving and SF6-free switchgear and circuit breakers to help provide continuous power supply for the new solar plant to operates at peak levels.”

Nida Deveci, sales manager and UGUR ACAR project manager for ABB Turkey, explained “The factory acceptance test (FAT) with our partner Voltalia was successful at the first attempt and proved that the collaboration and understanding was clear and good from the offset.

"They were very pleased with the speed of our responses and appreciated the technical revisions and adjustments we brought to the table to complete the process satisfactorily for all concerned parties.”
